Victron MultiPlus 24/3000/70-16

Code: VICTRON-MULTIPLUS-24-3000-70-16
Not rated
€991,87 €1 220 incl. VAT
In external warehouse
Delivery to:
29.01.2025

True to its name, the MultiPlus combines an inverter and charger in one streamlined package. Its myriad features include a true sine wave inverter, adaptive charging capabilities, PowerAssist hybrid technology, and a host of integration features to meet the needs of multiple systems.

The name is defined as:

  • Nominal battery voltage/power/charging current of the home battery-transfer switch (A)

Detailed information

Product detailed description

Key Features:

  • Unique PowerAssist feature
    The MultiPlus serves as overload protection from a limited AC source such as a generator or shore power. Initially, the battery charge is automatically reduced to prevent overload. If the overload persists, the MultiPlus takes secondary action by supplementing the generator or shore power with energy drawn from the battery, thereby reducing the load on the limited AC source.
  • Uninterruptible power supply (UPS function)
    During a power outage or when the shore power or generator power is disconnected, the inverter integrated in the Multi immediately switches on and seamlessly takes over the power supply to the connected loads. This transition takes place with remarkable speed, in less than 20 milliseconds, ensuring that computers and other electronic devices remain operational without any interruptions.
  • Virtually unlimited power thanks to parallel operation
    Up to six Multis can be connected in parallel to increase their power. In addition, three-phase or split operation is possible. For specific information on which models offer parallel, three-phase and split phase options, please refer to our data sheets.
  • Remote Monitoring and Control
    When paired with a GX device such as the Cerbo GX, you gain the ability to monitor and control your Multi and system(s) either locally (LAN) or remotely over the internet from anywhere in the world. This can be done using the free VRM app and the VRM portal website. Access is possible from a variety of devices including phones, tablets, laptops and PCs with multiple operating systems. The level of control is extensive, allowing you to customize your Multi and even automate tasks such as starting a backup generator, offering a comprehensive solution for efficiently managing your system.

Additional parameters

Category: Photovoltaics
Weight: 18 kg
Degree of protection (IP): IP20
Communication: VE.Bus
Nominal voltage: 230 V
Lenght: 218 mm
Width: 258 mm
Height: 362 mm
Power: 3000 W
Battery Voltage: 24 V
Rated Battery Charge Current: 70 A
Transfer switch: 16 A
