Soluna HV 15K
Code: SOLUNA-HV-15KProduct detailed description
SOLUNA HV PACK
Modern technology, combined with functionality and aesthetics, presents the Soluna HV Pack 10K/15K L-E as the ideal choice for any home or small business. You will appreciate not only its high performance, but also its ability to adapt to your individual needs.
Key features
- Wide Compatibility
The Soluna HV Pack can integrate seamlessly with many existing systems and hybrid inverters, providing flexibility in installation and expansion. - Easy Installation
The battery is designed to be quick and straightforward to install, simplifying the process and reducing the time needed to get it up and running - 10-year Warranty & 6000 cycles
The 10-year warranty ensures that you are investing in a product that will serve you reliably for many years. - Remote Updating and Monitoring
Modern technology allows you to monitor and update the battery remotely, giving you maximum control and visibility of its status.
Maximise your electrical potential!
Scalability up to 150kWh! With the innovative parallel box, you can now easily mix and match up to 10 of any module - whether 10K or 15K - for a staggering total output of 150kWh. Invest in flexibility that grows with your needs. Ensure your energy independence with the unrivalled scalability that Soluna offers.
Soluna eCloud: monitoring and management
- Constantly in real time
Monitor the performance and health of your systems continuously and get instant insights wherever you are. - History and data analysis
Gain detailed insights into the performance of your systems, track trends and make informed decisions based on historical analysis. - Automatic updates
Keep your system up-to-date with regular and automatic updates that bring new features and optimizations.
Safety and certifications
Soluna batteries are the result of a thorough development process focused on safety and quality. Each product undergoes rigorous testing and is certified to international safety standards. With integrated safety circuits and robust design, Soluna batteries provide reliable protection against potential hazards. With Soluna batteries, you are investing in superior safety and performance.
- IP54
Provides protection against dust ingress and splashing water - Cell Certification: UL1642
Certified to UL1642, which guarantees the safety and quality of individual battery cells. - Module Certification: IEC62619 & CE
Certified to IEC62619 international standards and the European CE mark of conformity, ensuring a high standard of safety and reliability.
Battery type | Lithium LFP |
Usable capacity (kWh) | 13.5 |
Rated voltage (V) | 384 |
Voltage (usable) range (V) | 336-420 |
Charging voltage (V) | 420 |
Discharge cut-off voltage (V) | 360 |
Charging/discharging current (nominal) (A) | 20/20 |
Charging/discharging current (max.) (A) | 40/40 |
Depth of discharge (DoD) (%) | 90 |
Maximum number of batteries in series | 10 |
Operating temperature (°C) | -10 to 50 |
Operating temperature (recommended) (°C) | 15 to 30 |
Storage temperature (°C) | -30 to 60 |
Humidity conditions (%) | 5 to 95 |
Altitude (m) | Max. 2,000 |
Cooling strategy | Natural convection |
Weight without packaging (kg) | 143 |
Manufacturer's warranty | 10-year standard warranty |
Additional parameters
Category: | Batteries for photovoltaics |
---|---|
Weight: | 178 kg |
Lenght: | 227 mm |
Width: | 654 mm |
Height: | 1205 mm |
Usable energy: | 15 kWh |
Brand: | Soluna |
Battery type: | High voltage |
Be the first who will post an article to this item!
SOLUNA, based in Shanghai, China, is a major battery manufacturer offering comprehensive solutions compatible with most inverters on the market. As its distributors, we bring you innovative energy solutions that are reliable, efficient and tailored to your needs.
