Fronius Wattpilot Go 11 J
Code: 1251Product detailed description
The Fronius Wattpilot comes in two versions and power categories of 11 kW and 22 kW: Home - a mounted charger for use at home - and Go, a portable solution for on the go. The charger can be easily controlled via the Solar.wattpilot app, which also allows you to choose between Eco and Next Trip mode.
INPUT DATA
| Frequency (Input) | 50 Hz |
|---|---|
| Network types | TT / TN / IT |
| Network connection | CEE32 plug red 5-pole / 30 cm including neutral wire |
| Rated current (configurable) | 6–16A 1-phase or 3-phase |
| Charging socket | Infrastructure socket type 2 with mechanical lock |
| Residual current device | 20 mA AC, 6 mA DC |
| Input cable cross-section | 2.5 mm² |
| Maximum charging power | 11 kW |
GENERAL DATA
| Dimensions / (width) | 155 mm |
|---|---|
| Dimensions (height) | 287 mm |
| Dimensions (depth) | 109 mm |
| Weight | 1.63 kg |
| Weight with packaging | 2.82 kg |
| Protection class | IP 55 |
| Installation | Indoor or outdoor 1) |
| Ambient temperature range | -25 °C to +40 °C (without direct sunlight) |
| Humidity | 5 % - 95% |
| Maximum altitude | 2000 m |
| Impact resistance | IK08 |
| Photovoltaic optimization | Dynamic charging with excess photovoltaic energy 1.38-11 kW (automatic switching 1 phase / 3 phases) |
| Network connection | WLAN 2) |
| Installation type | Vertical suspension |
| Average ambient temperature in 24 hours | Max. 35 °C |
| Communication protocols | OCPP 1.6 J |
| Optional adapters (can be ordered separately) | CEE32 red protected, camping plug CEE blue, protected plug 16A |
1) When installed outdoors, the Wattpilot must not be exposed to direct sunlight.
2) The Fronius Wattpilot supports the WLAN standards 802.11 b/g/n in the 2.4 GHz band with WEP, WPA, WPA2 and WPA3 protocols.
Additional parameters
| Category: | Portable EV chargers |
|---|---|
| Weight: | 3 kg |
| Brand: | Fronius |
